The Alphacool Rise Flat reservoir has an integrated pump top for powerful D5 pumps and comes with a VPP Apex pump. The combination of pump top and expansion tank is made entirely of acrylic. This makes maintenance and control of the water circuit much easier and gives the expansion tank a unique design. In addition, Alphacool's Rise Flat has 5 individually controllable 5V ARGB LEDs that create unique lighting effects. Thanks to the flat design, the reservoir can fit into even the tightest case.

Compact design, flexible use

Due to the flat, compact design and the high number of connections, the Rise Flat reservoir can be used flexibly and can also be installed in the tightest of spaces. With the help of the mounting kit included in the scope of delivery, the reservoir can be mounted free-standing in the case, on a radiator or at free fan positions (see mounting example).

Connection options

The Rise Flat expansion tank has a total of 5 inputs and one output. All connections use a G1/4" thread. The 5 inlets are perfectly placed over the entire expansion tank. This allows for easy filling and draining and facilitates maintenance of the entire water circuit.

Brilliant lighting

On the side of the expansion tank, 5 digitally addressable 5V ARGB LEDs can be installed, which create a unique, very noble-looking illumination. The digital ARGB LED lighting is connected via a JST 3-pin connector and can be controlled with an ARGB controller or an ARGB capable mainboard.

Technical data

• Dimensions: 120 x 120 x 50mm
• Weight: 565g
• Capacity: 200ml
• Material: Acrylic
• Pump compatibility: D5/VPP
• Connections: 6x G1/4“
• Maximum working temperature: 60 °C
• Pressure tested: 0.8 bar
• ARGB type: 3-pin 5V
