The TP-Link Omada ES216G V1.6 is designed to elevate networking performance with its capabilities. It supports up to 4000 VLANs and is equipped with 16 ports for 10/100/1000 Base-T connections, ensuring a robust and flexible network setup. With features like VLAN support, IGMP snooping, and Quality of Service (QoS), this switch optimizes traffic management and enhances performance for demanding applications. The device operates efficiently in various environments, with a wide temperature range and high humidity tolerance, ensuring reliable service even under challenging conditions. Built for longevity, the ES216G boasts a Mean Time Between Failures (MTBF) of over 213,000 hours and includes a sturdy metal housing. The switch also features functions such as cable diagnostics, bandwidth control, and port isolation. With support for Zero-touch provisioning (ZTP) and cloud management, network administrators can manage devices effortlessly. Whether rack-mounted or desktop, the ES216G is suitable for various deployment scenarios, making it a versatile choice for enhancing your network infrastructure.
Key Selling Points
  • Supports up to 4000 VLANs for flexible network configuration
  • 16 10/100/1000 Base-T ports ensure high-speed connectivity
  • Quality of Service (QoS) enhances traffic management
  • Metal housing and a high MTBF ensure reliability
  • Remote management through cloud capabilities simplifies administration
Product Features
With a switching capacity of 32 Gbps and a packet forwarding rate of 23.8 Mpps, the ES216G ensures that your data flows smoothly and efficiently, even under heavy load.
Featuring a metal housing and a MTBF of 213,114 hours, this switch is built to withstand harsh environments, providing long-term reliability and performance.
The device supports DHCP and can be remotely managed, allowing for seamless configuration and monitoring of network performance from virtually anywhere.
The TP-Link Omada ES216G includes VLAN support, IGMP snooping, and various storm control measures, ensuring optimal performance and network security.
Designed to be rack-mountable or suitable for desktop use, the switch can fit the needs of any workspace, making it versatile for different installation environments.
Attributes
Main Specifications
Capacity
Priority queues: 8VLAN groups: 32VLANs supported: 4000
Compliant Standards
IEEE 802.1p, IEEE 802.3x, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Device Type
Switch - 16 ports - managed
Dimensions (WxDxH)
29.4 cm x 14 cm x 4.4 cm
Enclosure Type
Rack-mountable
Features
Reset button, cloud managed, VLAN support, port isolation, Cable Diagnostics Function, QoS, loop prevention, IGMP snooping, fanless, metal housing, traffic prioritization, ZPT, security lock slot (cable lock sold separately), auto-negotiation, auto-uplink
Jumbo Frame Support
15KB
MAC Address Table Size
8K entries
Performance
Switching capacity: 32 GbpsPacket forwarding rate: 23.8 MppsPacket buffer size: 4 Mbit
Ports
16 x 10/100/1000Base-T
Power
AC 100-240 V (50/60 Hz) 0.3 A
Product Description
TP-Link Omada ES216G V1.6 - switch - 16 ports - managed - rack-mountable
Remote Management Protocol
DHCP
Routing Protocol
IGMP, IGMPv2, IGMPv3
Subtype
Gigabit Ethernet

EX-DEMO TP-Link ES216G - Omada 16-Port Gigabit Easy Managed Switch

Limit 1 per household
Condition Report: Refurbished unit from supplier, all accessories included
WA
  • BentleyApprox 1 business day
  • CockburnApprox 1 business day
  • Osborne ParkIn stock
  • WangaraApprox 1 business day
VIC
  • DandenongOut of stock
PLE Code
PLE-688689
Manufacturer
TP-Link
Boxed Weight
1.78
Model Number
EXD-ES216G
Warranty
3 Year PLE Standard Return to Base
