A product image of ASUS ProArt Z490 Creator 10G LGA1200 ATX Desktop Motherboard

ASUS ProArt Z490 Creator 10G LGA1200 ATX Desktop Motherboard

$699.00
Add Preorder to Cart
Add to Wishlist

ASUS ProArt Z490 Creator 10G LGA1200 ATX Desktop Motherboard

ASUS ProArt Z490 Creator 10G LGA1200 ATX Desktop Motherboard

Add Preorder to Cart
Add to Wishlist
Stock Availability

Bentley (WA)
Out of stock
Notify me
Cockburn (WA)
Out of stock
Notify me
Osborne Park (WA)
Out of stock
Notify me
Wangara (WA)
Out of stock
Notify me
WA Warehouse
Out of stock
Notify me
Heatherton (VIC)
Out of stock
Notify me
Product Information

PLE Code

PLE-641619

Manufacturer

ASUS

Boxed Weight

1kg

Model Number

PROART Z490-CREATOR 10G

Warranty

3 Year PLE Standard Return to Base
Share This Product On Socials
Product Description
Every aspect of ASUS ProArt motherboards is built to remove barriers and deliver optimal performance to content creators who work in 3D modeling and rendering, animation or media production. The series empowers you to concentrate on your creativity and expand what is possible.
Product Specifications
Form Factor
ATX
Chipset
Z490
Socket
LGA1200
Memory Type
DDR4
PCB Colour
Black
RGB Type
A-RGB & RGB
Product Description
ASUS ProArt Z490-CREATOR 10G - motherboard - ATX - LGA1200 Socket - Z490
Product Type
Motherboard - ATX
Chipset Type
Intel Z490
Processor Socket
1 x LGA1200 Socket
Compatible Processors
(supports 10th Generation Intel Core / Pentium Gold / Celeron)
Max RAM Size
128 GB
RAM Supported
4 DIMM slots - DDR4, non-ECC, unbuffered
Storage Ports
6 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports
USB-C Gen2, USB-C Gen1, USB 3.2 Gen 1, USB 3.2 Gen 2 2 x USB-C Gen 2 + 4 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + (1 x USB-C Gen 1 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio
HD Audio (8-channel)
LAN
2.5 Gigabit Ethernet
Max Processors Qty
1
Max Size
128 GB
Technology
DDR4
Bus Clock
2400 MHz, 2133 MHz, 2666 MHz, 2800 MHz (O.C.), 2933 MHz (O.C.), 3000 MHz (O.C.), 3200 MHz (O.C.), 3300 MHz (O.C.), 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4500
Supported RAM Integrity Check
Non-ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture
Type
HD Audio (8-channel)
Audio Codec
SupremeFX (S1220A)
Compliant Standards
High Definition Audio
Network Controller
Intel I225-V
Network Interfaces
2.5 Gigabit Ethernet
Expansion Slots
1 x CPU4 x DIMM 288-pin2 x PCIe 3.0 x16 (dual x8 mode; single card: x16 mode)1 x PCIe 3.0 x16 (x4 mode)2 x PCIe 3.0 x1
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5SATA-600 / PCIe 3.0 -connectors: 1 x M.2PCIe 3.0 -connectors: 1 x M.2
RAID Features
Intel Rapid Storage Technology
Interfaces
1 x LAN (2.5Gigabit Ethernet)1 x audio line-in - mini-jack1 x audio line-out - mini-jack1 x microphone - mini-jack1 x TOSLINK2 x USB 3.2 Gen 14 x USB 3.2 Gen 21 x audio line-out (center/subwoofer) - mini-jack1 x audio line-out (rear) - mini-jack2 x Displa
Internal Interfaces
4 x USB 2.0 - header1 x USB-C Gen 1 - header2 x USB 3.2 Gen 1 - header1 x Thunderbolt - header1 x audio - header1 x serial - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
BIOS Type
AMI
BIOS Features
UEFI BIOS
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
Hardware Features
Jack retasking, ASUS Q-Design, ESD Guards, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, CrashFree BIOS 3, audio jack detect technology, ASUS EPU (Energy Processing Unit), ASUS Q-Shield, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, AMD 3-way CrossFireX techno
Included Accessories
I/O back plate, 1 x M.2 screw, CPU fan holder, rubber pad, Hyper 10G LAN card
Cables Included
4 x Serial ATA cable1 x DisplayPort cable
Software Included
Drivers & Utilities, ASUS AI Charger, ASUS AI Suite III, ASUS EZ Update, ASUS Turbo App, ASUS EZ Flash 3, WinRAR, ASUS ProArt Creator Hub
Width
30.5 cm
Depth
23.4 cm
From the manufacturer
A large marketing image providing additional information about the product ASUS ProArt Z490 Creator 10G LGA1200 ATX Desktop Motherboard - Additional alt info not provided
This document and other documents provided pursuant are for informational purposes only. The information type should not be interpreted to be a commitment on the part of the Supplier. The Supplier cannot guarantee the accuracy of information presented. The user assumes the entire risk as to the accuracy and the use of this document. This document may include screenshots from the manufacturer's website which may be used for multiple variations of this product. The model number supplied at the top of this page (explicitly specified as "Model Number") is the exact model item you will receive.
