Intel NUC Gen8 Islay Canyon i5 Mini PC w/8GB RAM
669.0000

Intel NUC Gen8 Islay Canyon i5 Mini PC w/8GB RAM

SKU BXNUC8I5INHX
$669.00
Buy Now
Add to Wishlist
Shipping Availability
Enter your postcode
Western Australia : Enter your postcode for more information
Eastern States : Immediate Dispatch Available
Pickup Availability
Victoria
Heatherton
:
In Stock

Western Australia
Bentley
:
In Stock

Cockburn
:
Taking pre-orders

Osborne Park
:
Taking pre-orders

Wangara
:
Taking pre-orders

PLE Code: PLE-637622
Model Number: BXNUC8I5INHX
Manufacturer: Intel
Warranty: 3 Year PLE Standard Return to Base
Boxed Weight: 1.22kg
The Intel NUC is a powerful mini PC with entertainment, gaming, and productivity features, including a customizable board that is ready to accept the memory, storage, and operating systems that you want.

  • Go small, get big
  • Works hard, plays hard
  • Energy optimized
  • Easy to operate

Intel NUC mini PCs deliver the sky-high performance you expect in a PC that fits in the palm of your hand. Get ready to be astonished by small.
Built around fast processors, Intel NUC PCs are optimized platforms. Get awesome performance with productivity tasks like web and spreadsheets, content creation with photos and videos, and entertainment.

Main Specifications
Product Description
Intel Next Unit of Computing Kit 8 Mainstream-G kit - mini PC - Core i5 8265U 1.6 GHz - 8 GB
Type
PC barebone - mini PC
Processor
1 x Intel Core i5 (8th Gen) 8265U / 1.6 GHz (3.9 GHz) (Quad-Core)
Processor Main Features
Intel Virtualization Technology, Intel AES New Instructions
Cache Memory
6 MB
Cache Per Processor
6 MB
RAM
8 GB DDR3 SDRAM
Storage Controller
SATA (SATA 6Gb/s)
Hard Drive
No HDD
Optical Storage
No optical drive
Card Reader
Yes
Graphics Controller
AMD Radeon R540X
Video Memory
2 GB GDDR5 SDRAM
Audio Output
7.1 channel surround
Networking
GigE, 802.11a, 802.11b/g/n, 802.11ac, Bluetooth 5.0
Power
DC 19 V
OS Provided
No operating system
Dimensions (WxDxH)
11.7 cm x 11.2 cm x 5.1 cm
Manufacturer Warranty
Limited warranty - 3 years

Extended Specifications
General
Type
PC barebone
Product Form Factor
Mini PC
Sensors
Infrared (IR) sensor
Processor / Chipset
CPU
Intel Core i5 (8th Gen) 8265U / 1.6 GHz
Max Turbo Speed
3.9 GHz
Number of Cores
Quad-Core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Not upgradable
Processor Main Features
Intel Virtualization Technology, Intel AES New Instructions
Cache Memory
Installed Size
6 MB
Cache Per Processor
6 MB
RAM
Installed Size
8 GB
Technology
DDR3 SDRAM
Rated Memory Speed
1866 MHz
Features
Dual channel memory architecture, Load-Reduced DIMM (LRDIMM)
Hard Drive
Type
No HDD
Storage Controller
Type
2 x SATA
Controller Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Card Reader
Type
Card reader
Supported Flash Memory Cards
SDXC UHS-I Memory Card
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
AMD Radeon R540X
Video Memory
2 GB GDDR5 SDRAM
Video Interfaces
HDMI, DisplayPort
Audio Output
Sound Output Mode
7.1 channel surround
Compliant Standards
High Definition Audio
Networking
Ethernet Controller
Intel I219-V
Wireless LAN Supported
Yes
Wireless NIC
Intel Wireless-AC 9560
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Expansion / Connectivity
Bays
1 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 1 (free) x M.2 Card - 2280
Interfaces
3 x USB 3.1 Gen 2 - Type A (1 front, 2 rear) (one of them is charging)1 x USB-C 3.1 Gen 21 x HDMI1 x Mini DisplayPort1 x LAN (Gigabit Ethernet) - RJ-451 x headphones/microphone - mini-jack
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
ACPI, ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, AS/NZS 4268, FCC Part 15 E, BSMI CNS 13438, CISPR, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, EN 301 489-1, KN32, KN35, AS/NZS 2772.2, EN 301 893, IEC/EN/UL 60950-1, EN 55032, EN 301 489-3, EU RoHS, IEC/EN/UL 62368-1, EN 301 489-17, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32
Power
Device Type
Power adapter
Nominal Voltage
DC 19 V
Power Provided
90 Watt
Operating System / Software
OS Provided
No operating system
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Width
11.7 cm
Depth
11.2 cm
Height
5.1 cm
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
