ID-COOLING FrostFlow 240VGA GPU Liquid Cooler
109.0000

ID-COOLING FrostFlow 240VGA GPU Liquid Cooler

SKU FROSTFLOW 240VGA
$109.00
Buy Now
Add to Wishlist
Shipping Availability
Enter your postcode
Western Australia : Enter your postcode for more information
Eastern States : Immediate Dispatch Available
Pickup Availability
Victoria
Heatherton
:
In Stock

Western Australia
Bentley
:
Out Of Stock

Cockburn
:
In Stock

Osborne Park
:
In Stock

Wangara
:
Out Of Stock

PLE Code: PLE-633334
Model Number: FROSTFLOW 240VGA
Manufacturer: ID-COOLING
Warranty: 2 Year PLE Standard Return to Base
Boxed Weight: 1.70kg
Built for Mainstream Gaming VGA Card Cooling. Provides extra cooling for VRAM, TDP 300W.



VGA Compatibility
  Mounting Holes
 58.4*58.4mm; 53.3*53.3mm;
 GTX1080/1070/1060/1050/980Ti/980/970/960, etc.; AMD R390/290/280 Series
 TDP
 300W
 Radiator Dimension
 274×120×27mm
 Radiator Material
 Aluminum
 Tube Material
 EPDM Rubber
 Tube Length
 380mm
 Waterblock Dimension
 Ф65×32.5mm
 Cold Plate Material
 Copper
 Pump Current
 0.25A
 Pump Speed
 2500RPM
 Pump Bearing
 Ceramic Bearing
 Pump Life Expectancy
 50,000 Hrs
 Pump Noise Level
 25dB(A)
 Fan Dimension
 120×120×25mm
 Fan Dimension
 92×92×15mm
 Included Fans
 2pcs
 Included Fans
 1pcs
 Fan Speed
 700~1500RPM
 Fan Speed
 1500RPM
 Max. Air Flow
 62CFM
 Max. Air Flow
 24.5CFM
 Max. Static Pressure
 3.2mmH2O
 Max. Static Pressure
 1.25mmH2O
 Noise
 18~26.4dB(A)
 Noise
 22.8dB(A)
 Rated Voltage
 12VDC
 Rated Voltage
 12VDC
 Operating Voltage
 10.8~13.2VDC
 Operating Voltage
 10.8~13.2VDC
 Started Voltage
 7VDC
 Started Voltage
 7VDC
 Rated Current
 0.18A
 Rated Current
 0.05A
 Power Input
 2.16W
 Power Input
 0.6W
 Bearing Type
 Hydraulic Bearing
 Bearing Type
 Hydraulic Bearing


GPU COMPATIBILITY LIST (According to Mounting Holes)
 53.3*53.3mm
 NVIDIA
 GeForce GTS 450, 250
 AMD
 Radeon R9 290X, 290, 285, 280X, 280, 270X, 270
 Radeon R7 265
 58.4*58.4mm
 NVIDIA
 GeForce GTX 1080/1070/1060 Series
 GeForce GTX 980Ti, 980, 970, 960, Titan Series
 GeForce GTX 780Ti, 780, 760Ti, 760
 GeForce GTX 680Ti, 680, 670, 660Ti, 660, 650Ti, 650
NVIDIA 20 Series
 GeForce RTX Reference Edition Only
 Note: Above listed VGA Card models are based on reference design. Non-reference designed cards from different brands may have different layout. Please carefully check your card dimensions before installation.
