A product image of ASUS Tinker Board

ASUS Tinker Board

$99.00
Add to Cart
Add to Wishlist

ASUS Tinker Board

A large main feature product image of ASUS Tinker Board
A small tile product image of ASUS Tinker Board
A small tile product image of ASUS Tinker Board

ASUS Tinker Board

Add to Cart
Add to Wishlist
Stock Availability

Bentley (WA)
In stock
Cockburn (WA)
In stock
Osborne Park (WA)
In stock
Wangara (WA)
In stock
WA Warehouse
In stock
Heatherton (VIC)
In stock
Product Information

PLE Code

PLE-628845

Manufacturer

ASUS

Boxed Weight

0.15kg

Model Number

TINKER BOARD/2GB

Warranty

1 Year PLE Standard Return to Base
Share This Product On Socials
Associated Items
Product Description
Tinker Board is a Single Board Computer (SBC) in an ultra-small form factor that offers excellent performance while leveraging outstanding mechanical compatibility. The Tinker Board offers makers, IoT enthusiasts, hobbyists, PC DIY enthusiasts and others a reliable and extremely capable platform for building and tinkering their ideas into reality.
Product Summary
Great performance
With its powerful and modern quad-core ARM-based processor Tinker Board offers significantly improved performance. To provide the flexibility needed for different builds and projects, Tinker Board features LPDDR3 dual-channel memory. Tinker Board is also equipped with an SD 3.0 interface that offers significantly faster read and write speeds to expandable microSD cards used for the OS, applications and file storage.
Robust GPU performance and functionality
Featuring a powerful but energy-efficient design, Tinker Board supports next-generation graphics and GPU computing API's. Tinker Board's GPU and fixed-function processors allow for a wide range of uses, including high-quality media playback, gaming, computer vision, gesture recognition, image stabilization and processing, as well as computational photography and more. Multimedia enthusiasts will appreciate the fixed-function H.264 and H.265 playback support, including playback of HD and UHD video.
HD audio quality
Further improving on key areas found lacking on many SBC boards, Tinker Board is equipped with an HD codec that supports up to 24 bit / 192 kHz audio. Its integrated audio jack supports audio output and a microphone in, without an extension module.
Maker-friendly, with IoT connectivity
Tinker Board features standard maker connectivity options, including a 40-pin GPIO interface that allow for interfacing with a range inputs from buttons, switches, sensors, LEDs, and much more. Tinker Board is equipped with one DSI MIPI connection for displays and touchscreens. The secondary CSI MIPI connection is for connection to compatible cameras allowing for computer vision, and much more. Tinker Board also features Gbit LAN for Internet and network connectivity. A dedicated bus resource designed for the LAN port ensures consistent Ethernet performance. The integrated Wi-Fi and Bluetooth controller on the Tinker Board is shielded with a metal cover to ensure minimal interference and improved radio performance. An integrated IPEX antenna header allows for easy antenna replacement or upgrades. Tinker Board also features a full-size HDMI output. Additionally, it includes four USB 2.0 ports for extensive peripheral and accessory connectivity.
Enhanced DIY design
Careful consideration went into the design and development of the Tinker Board to ensure that it provides a superior user experience for first-time builders or for seasoned hobbyists. Builders will appreciate the color-coded GPIO header, which makes it easy to recognize respective pin headers. The PCB features silk-screening with a connection header and location callouts, for improved connection clarity. The onboard MIPI headers also feature color-coded pull tabs.
USB speed
Tinker Board offers superior read and write performance with external storage drives, allowing quicker read and write speeds. This improves workflow, copying, backups and overall file usage.
Wi-Fi performance
Tinker Board Wi-Fi performance is more robust, allowing for improved signal reception.
Product Specifications
Product Description
ASUS Tinker Board - single-board computer
Processor
Rockchip RK3288 1.8 GHz (Quad-Core)
Memory
microSD - RAM 2 GB
Graphics Accelerator
Mali T764
Wireless Protocol
802.11b/g/n, Bluetooth 4.0 EDR
Wired Protocol
Gigabit Ethernet
Power Source
USB port
Weight
55 g
Product Type
Single-board computer
Type
Rockchip RK3288
Clock Speed
1.8 GHz
Number of Cores
Quad-Core
Technology
LPDDR3 SDRAM
Installed Size
2 GB
Supported Flash Memory Cards
microSD
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0 EDR
Interface Provided
LAN - RJ-454 x USB 2.0 - Type AGPIO - 40 pin IDCDSI - ZIFSPDIFCSI - ZIFHDMI output - Type AAudio line-out/microphone - mini-jack
From the manufacturer
A large marketing image providing additional information about the product ASUS Tinker Board - Additional alt info not provided
This document and other documents provided pursuant are for informational purposes only. The information type should not be interpreted to be a commitment on the part of the Supplier. The Supplier cannot guarantee the accuracy of information presented. The user assumes the entire risk as to the accuracy and the use of this document. This document may include screenshots from the manufacturer's website which may be used for multiple variations of this product. The model number supplied at the top of this page (explicitly specified as "Model Number") is the exact model item you will receive.
